| Pattern | KQ-2041 - |
| Max Pressure | 2900Psi/200Bar |
| Flow Value | 10.8Gpm / 41Lpm |
| Power | 24 HP |
| Pump | AR high pressure pump |
| Machine | Diesel start |
| Fuel | Diesel |
| Voltage | 12V |
| Pattern | KQ-2015H |
| Max Pressure | 2900Psi/200Bar |
| Flow Value | 3.9Gpm / 15Lpm |
| Rotating speed | 1400R/min |
| Voltage/Frequency | 380V/50HZ |
| Electric motor | 5.5KW, 4P |
| Fuel | Diesel oil |
| Maximum temperature | 90° degrees Celsius |
| Oil consumption | 6L/h |
| Pattern | KQ-2013LH |
| Max Pressure | 2900Psi/200Bar |
| Flow Value | 3.4Gpm / 13Lpm |
| Rotating speed | 1400R/min |
| Lithium battery | 72V/150 AH |
| Electric motor | 5KW |
| Fuel | Diesel oil |
| Maximum temperature | 90° degrees Celsius |
| Oil consumption | 6L/h |
| Pattern | KQ-1515DH |
| Max Pressure | 2175Psi/150Bar |
| Flow Value | 3.9Gpm / 15Lpm |
| Rotating speed | 3600R/min |
| Fuel | Diesel oil |
| Maximum temperature | 90° degrees Celsius |
| Oil consumption | 6L/h |
| Matching power | 9HP |
| Pattern | KQ-1015HW |
| Max Pressure | 1450Psi/100Bar |
| Flow Value | 3.9Gpm / 15Lpm |
| Rotating speed | 1400R/min |
| Pump | 360 |
| Electric motor | 2.2KW, 4P |
| Fuel | Diesel oil |
| Maximum temperature | 90° degrees Celsius |
| Oil consumption | 5L/h |
| Model: KQ-1015H | ||
| Voltage: 220V | ||
| Pressure: 10Mpa | ||
| Flow rate: 15L/min | ||
| Power: 2.2kw | ||
| Rotation speed: 1400R/min | ||
| Fuel: Diesel | ||
| Consumption: 5L/h | ||
| Water Temperature: 90 °C |
| Pattern | 3WZ-2600 - | 3WZ-3200A |
| Max pressure | 2610Psi/180Bar | 3190Psi/220Bar |
| Flow rate | 3.9Gpm / 15Lpm | 3.9Gpm / 15Lpm |
| Rotating speed | 3600r/min | 3600r/min |
| Pump | RRV4G36 | RRV4G36 |
