Casis |
Casis | WZ chassis |
| Motor | 1500W heavy duty motor, strong output, soft start, anti-tilt | |
| Power | 60V45A capacity are all made of CW maintenance-free lead-acid batteries, with stable performance, long life, and stable working voltage | |
| Charger | New national standard full automatic shutdown smart charger | |
| Climbing ability | ≤15° | |
| Residents | 1 | |
| Maximum speed | 28Km/h | |
| Frame | High quality carbon structural steel, automotive grade electrophoretic, anti-fade high temperature baking paint, long-term rust resistance | |
| Back bridge | Customized heavy-duty rear axle for special vehicles | |
| Braking System | Front and rear mechanical brakes, parking brake | |
| Suspension | The front suspension is thickened double-tube shock absorption, and the rear suspension steel plate is non-independent shock absorption | |
| Tire size | Front: 400-12 Rear: 400-12 | |
| sign | Headlight, front turn signal, rear turn signal, brake light, horn | |
| Full size | L: 3000mm W: 1050mm H: 1500mm | |
| Sit | High density foam sponge | |
| Body cover | Material | Galvanized sheet |
| Dimensions | L: 1500mm W: 1000mm H: 800mm | |
| Tank | Material | Rotomoulding tank, non-leaking, corrosion resistant; 2 inlet holes |
| Dimensions | 0,55 m³ | |
| Cleaning system | Motor | LF 190FD 15HP high performance air cooling Four stroke OHV gasoline engine, electric start + hand start |
| Water pump | Pressure: 250kg-280kg/cm² | |
| Hose reel | 15-meter heavy-duty double-arm automatic hose reel, freely retractable, efficient and convenient | |
| Filter | 80-mesh water filter, clear position, easy to clean | |
| Spray device | High pressure washing gun, front double spout, rear sprinkler | |
| High pressure ball valve | 304 stainless high pressure ball valve, corrosion resistant, high pressure resistant (31.5Mpa) | |
| Waterway switching | Rust-proof high-pressure ball valve switching, easy to operate. |
