Good cleaning and disinfection effect, and low labor intensity. It is suitable for livestock farms, farms, road disinfection in the field, and disinfection and cleaning of transport vehicles.
Main function: The combination of soil dirt removal, high temperature physical disinfection, and chemical disinfection of drugs is better. A new generation of folding high-pressure spraying device is added to the front row. The working range in normal operation is 1.4m. After opening, it reaches 2.6m, and the spraying range reaches 3m. High operating efficiency, small size, light weight, strong pass, low noise, pure electric drive is economical and environmentally friendly. The vehicle is equipped with an operation alarm device and a night reflective strip, which is suitable for day and night operations. The unique "working speed mode", "water level alarm" and "speed adjustment" can improve the safety factor of the operation, and the high-quality electric four-wheel chassis is easy to operate, and ordinary workers can operate it.
| Electric | Pattern | Electric high temperature and high pressure cleaning car | Battery | 12V120AH/6 customized battery | Charger | Vehicle-mounted smart charger | |||
| Mastering | Domestic intelligent air conditioning controller | Motor | 4KW AC motor | Charging | 6-8 hours (80% discharge rate) | ||||
| Technical parameters | Input voltage | 220V | Pump flow | 15L/min | Capacity | 1000L | |||
| L*W*H | 3700*1200*1900 mm | Rotary sprinklers | Y | Tank cleaning port | Y | ||||
| Weight | 600 KG | Fan nozzle | 0°,15°,25°,45° | Lithium battery | 72V150AH | ||||
| Load | 2000 KG | Flushing method | handheld rinse | High temperature overheat protection | Y | ||||
| Front and rear tracks | 1150 millimeters | Control valve | hydraulic valve | Max pressure | 20 MPA | ||||
| Wheelbase | 2800 millimeters | Heating the boiler | 100 °C | Pressure adjustable | Y | ||||
| Minimum ground distance | 136 millimeters | Braking distance | ≤5M | High-pressure gun | Y | ||||
| Tank material | Rotomolding | Residents | 2 | Length of outlet pipe | 15 minutes | ||||
| Water level observation | Y | Maximum speed | 27km/h | Pump drive mode | Lithium battery | ||||
| Tank draining | Y | Max slope | 25° | Fuel | Diesel | ||||
| Starting method | Motor | Minimum turning radius | 5 minutes | ||||||
| High pressure pump | Italy AR | Bodywork | Sheet metal spray | ||||||
| Car body | Sit | Double seat front row (double seat + leather fabric + high resistance PU, with armrest) | rearview mirror | Manual exterior rearview mirror | |||||
| Agency | Load-bearing frame structure + PPC engineering plastic molded parts (for automobiles) | Signal light | Combined headlamps, turn signals, combined taillamps, brake lights, electric horns | ||||||
| Tools | Combination instruments (including front and rear reversing, lights, horn, power indicator and other signals) | Switch | Start switch, light switch, forward and reverse gear switch, warning light and other rocker switches | ||||||
| Inverted image | High-definition display screen, high-precision reverse imaging camera | Frame | Steel | ||||||
| LED Display | Facultative | Steering | Polyurethane foam steering wheel | ||||||
| Chassis system | Transmission | Stepless speed control system | Rear axle & suspension | Integral full-floating high and low speed rear axle, high-strength leaf springs | |||||
| Steering | Rack and pinion steering machine | Braking System | Rear two-wheel mechanical brake, parking brake device | ||||||
| Front axle and suspension | Integral shock absorbing damping suspension + coil spring | Tires | Tire wire radial 155 / R12LT |
||||||
| Disinfectant system | Front row high pressure nozzle | Retractable, with disinfection spray function | |||||||
| The length in normal operation is 1.4m, the length in extended operation is 2.6m, and the spraying range is 3m | |||||||||
| Pharmaceutical injector | One piece plus fixed quantity adjustment | ||||||||
